Endurant XD PRO PTO
OMFB introduces its latest range of pneumatic clutch PTOs specifically designed for the Eaton Endurant XD and XD PRO automated transmissions.
Engineered for on-highway and off-highway applications, these PTOs deliver reliable power transmission and are built to withstand demanding operating conditions.
They feature multiple ratios, rear output orientation, and a bottom-side mounting design, offering flexibility and performance tailored to modern fleet requirements.
Specifically developed to overcome exhaust clearance issue on new Kenworth T610, T610SAR, T410, and T410SAR models.
Engineered for on-highway and off-highway applications, these PTOs deliver reliable power transmission and are built to withstand demanding operating conditions.
They feature multiple ratios, rear output orientation, and a bottom-side mounting design, offering flexibility and performance tailored to modern fleet requirements.
Specifically developed to overcome exhaust clearance issue on new Kenworth T610, T610SAR, T410, and T410SAR models.
Characteristics
• Mounting Side: Bottom
• Output Position: Rear
• Rotation: Clockwise
• Internal Ratios: 1:1.13, 1:0.92, 1:0.81, 1:0.66
• Max Torque Range: From 300 Nm up to 520 Nm
• Speed at 1000 RPM Engine: From 1044 rpm up to 1802 rpm depending on ratio
• Output Position: Rear
• Rotation: Clockwise
• Internal Ratios: 1:1.13, 1:0.92, 1:0.81, 1:0.66
• Max Torque Range: From 300 Nm up to 520 Nm
• Speed at 1000 RPM Engine: From 1044 rpm up to 1802 rpm depending on ratio
Advantages
• Engineered for Endurant XD & XD PRO – Designed to meet the demands of Eaton's latest transmission platforms
• High Performance – Delivers superior torque output across various ratios
• Compact and Lightweight – Weighs just 18.5 kg, making it ideal for space-sensitive installations
• Durable and Reliable – Built with robust materials to endure challenging conditions
• High Performance – Delivers superior torque output across various ratios
• Compact and Lightweight – Weighs just 18.5 kg, making it ideal for space-sensitive installations
• Durable and Reliable – Built with robust materials to endure challenging conditions
Features & Benefits
• Rear Output Configuration – Simplifies integration with rear-mounted hydraulic systems
• Flexible Ratio Selection – Allows users to choose the optimal speed-torque combination
• Efficient Pneumatic Engagement – Ensures smooth and responsive PTO operation
• Complete with Mounting Kit – Includes all necessary components for straightforward installation
• Flexible Ratio Selection – Allows users to choose the optimal speed-torque combination
• Efficient Pneumatic Engagement – Ensures smooth and responsive PTO operation
• Complete with Mounting Kit – Includes all necessary components for straightforward installation
Product focus
This new OMFB PTO series is purpose-built for Eaton Endurant XD and XD PRO gearboxes used in on-road and off-road vehicles.
Whether it’s logistics, construction, or specialised transport, these PTOs deliver high torque, reliable engagement, and application versatility.
The range includes four distinct internal ratios to suit various operational needs, supporting efficient power delivery to auxiliary systems.
Whether it’s logistics, construction, or specialised transport, these PTOs deliver high torque, reliable engagement, and application versatility.
The range includes four distinct internal ratios to suit various operational needs, supporting efficient power delivery to auxiliary systems.
Frequently Asked Questions
What vehicles are these PTOs compatible with?
These PTOs are designed for vehicles equipped with Eaton Endurant XD and XD PRO automated transmissions.
What is the maximum torque output available?
The PTOs support a maximum torque of up to 520 Nm, depending on the selected ratio.
What ratios are available?
Four internal ratios are available: 1:1.13, 1:0.92, 1:0.81, and 1:0.66, providing flexible speed and torque combinations.
What is the mounting configuration?
All models mount to the bottom side of the transmission and offer a rear output with clockwise rotation.
What’s included in the mounting kit?
Each unit is delivered with a dedicated mounting kit (P/N 15400306023) for easy installation.
These PTOs are designed for vehicles equipped with Eaton Endurant XD and XD PRO automated transmissions.
What is the maximum torque output available?
The PTOs support a maximum torque of up to 520 Nm, depending on the selected ratio.
What ratios are available?
Four internal ratios are available: 1:1.13, 1:0.92, 1:0.81, and 1:0.66, providing flexible speed and torque combinations.
What is the mounting configuration?
All models mount to the bottom side of the transmission and offer a rear output with clockwise rotation.
What’s included in the mounting kit?
Each unit is delivered with a dedicated mounting kit (P/N 15400306023) for easy installation.
